Bridon® 35LS is a conventional low rotation resistant rope consisting of three layers of strands the inner two layers spun in the opposite direction to the outer layer of strands manufactured in accordance with EN 12385.
Bridon® 35LS is a conventional low rotation resistant rope consisting of three layers of strands the inner two layers spun in the opposite direction to the outer layer of strands manufactured in accordance with EN 12385.
Note: for more detailed information please download the brochure above.
| Diameter | Nominal length mass |
Minimum Breaking Force EIP/1960 |
|
|---|---|---|---|
| mm | kg/m | kN | Tonnes (metric) |
| 10 | 0.45 | 75.5 | 7.69 |
| 11 | 0.54 | 91.3 | 9.31 |
| 12 | 0.65 | 109 | 11.1 |
| 13 | 0.76 | 128 | 13.0 |
| 14 | 0.88 | 148 | 15.1 |
| 15 | 1.01 | 170 | 17.3 |
| 16 | 1.15 | 193 | 19.7 |
| 18 | 1.46 | 244 | 24.9 |
| 19 | 1.62 | 272 | 27.8 |
| 20 | 1.80 | 302 | 30.8 |
| 21 | 1.98 | 333 | 33.9 |
| 22 | 2.18 | 365 | 37.2 |
| 23 | 2.38 | 399 | 40.7 |
| 24 | 2.59 | 435 | 44.3 |
| 25 | 2.81 | 472 | 48.1 |
| 26 | 3.04 | 510 | 52.0 |
| 28 | 3.53 | 592 | 60.3 |
| 32 | 4.61 | 773 | 78.8 |
This table is for guidance purpose only with no guarantee or warranty (express or implied) as to its accuracy. The products described may be subject to change without notice, and should not be relied on without further advice from Bekaert.
