Drum Winder Ropes

Bridon® drum winder ropes offer high strength and superior fatigue performance. Drum winders are used in vertical shaft hoisting for very shallow mines (<500m). They are also used in mines with the max depth realised in shaft with a single shaft depth >2000m.

Filters

Remove filters

article-search-icon article-clear-icon
14 items
14 items
Bridon Tiger® 6T Compound Bristar®

Bridon Tiger® 6T Compound Bristar®

The Bridon Tiger® 6T Compound Bristar® are the most commonly used rope construction for shaft hoisting. Excellent performance on ultra-deep drum winders and most robust rope on friction winders. Advanced diameter stability and lifetime with a Bristar® core.
WRI® PS 620

WRI® PS 620

In the crane and industrial industry, the WRI® PS 620 rope is a general purpose 6 strand galvanized rope produced with a steel core, fully lubricated during manufacture produced in accordance with EN 12385. In underground mining, specially selected wire tensile grades and 6 strand construction enhance wear resistance. Specially formulated lubrication enhances wear properties, increases rope performance, and reduces environmental impact due to fly-off and the calibrated cut lengths and custom pad eyes simplify installation and reduce down-time. Excellent value for less demanding applications.
WRI® Tri-MAX

WRI® Tri-MAX

A well-proven 6x27 langs-lay flattened triangular strand construction provides 2.5 times the contact area of a round strand rope. Designed for increased rope strength, wear resistance and fatigue life, and exceptional resistance to drum crushing. The (3/3) triangular strand center construction provides the best strength/performance combination for drums with a recommended D/d ratio of 80/1.
Bridon Tiger Dyform® 6R

Bridon Tiger Dyform® 6R

The Bridon Tiger Dyform® 6R is a high strength 6 strand rope on friction winders with reliable performance.
WRI® DyPac 34

WRI® DyPac 34

DyPac strand enhancement of a 34x7 (LCD) construction provides additional performance, an increase in strength of approximately 15%, reduced sheave and drum wear, and significantly enhanced drum spooling. As a result, operating depths can be extended up to approximately 6000 ft. (1830 m).
Bridon Tiger® 6R Bristar®

Bridon Tiger® 6R Bristar®

Bridon Tiger® 6R Bristar® is the most common used rope on friction winders with reliable performance, advanced diameter stability and lifetime with a Bristar® core.
Bridon Tiger Dyform® 24LS / 24LS PI

Bridon Tiger Dyform® 24LS / 24LS PI

The Bridon Tiger Dyform® 24 LS is the most robust rotation resistant hoisting rope with superior performance on friction hoists with a high breaking strength. The dyformed strand are giving a contact on the lining and the sheaves. With a PI Intrusion of the core, the rope reaches excellent diameter stability when high thread pressure becomes an issue.

Bridon Tiger Dyform® 34LR / 34LR PI

Bridon Tiger Dyform® 34LR / 34LR PI

The Bridon Tiger Dyform® 34LR offers high strength, excellent spooling on multi-layer drums, with the highest flexibility. With a PI Intrusion of the core, the rope reaches excellent diameter stability when high thread pressure becomes an issue.
Bridon Tiger® 34M

Bridon Tiger® 34M

The Bridon Tiger® 34M construction is a rotation resistant rope in a 3-layer construction with synthetic fibre core. The rope is flexible and provides easy handling and installation. The Bridon Tiger® 34M can be used as a hoist or a balance rope.
Bridon Tiger® 6T Compound Bristar®

Bridon Tiger® 6T Compound Bristar®

The Bridon Tiger® 6T Compound Bristar® are the most commonly used rope construction for shaft hoisting. Excellent performance on ultra-deep drum winders and most robust rope on friction winders. Advanced diameter stability and lifetime with a Bristar® core.
WRI® PS 620

WRI® PS 620

In the crane and industrial industry, the WRI® PS 620 rope is a general purpose 6 strand galvanized rope produced with a steel core, fully lubricated during manufacture produced in accordance with EN 12385. In underground mining, specially selected wire tensile grades and 6 strand construction enhance wear resistance. Specially formulated lubrication enhances wear properties, increases rope performance, and reduces environmental impact due to fly-off and the calibrated cut lengths and custom pad eyes simplify installation and reduce down-time. Excellent value for less demanding applications.
WRI® Tri-MAX

WRI® Tri-MAX

A well-proven 6x27 langs-lay flattened triangular strand construction provides 2.5 times the contact area of a round strand rope. Designed for increased rope strength, wear resistance and fatigue life, and exceptional resistance to drum crushing. The (3/3) triangular strand center construction provides the best strength/performance combination for drums with a recommended D/d ratio of 80/1.
Bridon Tiger Dyform® 6R

Bridon Tiger Dyform® 6R

The Bridon Tiger Dyform® 6R is a high strength 6 strand rope on friction winders with reliable performance.
WRI® DyPac 34

WRI® DyPac 34

DyPac strand enhancement of a 34x7 (LCD) construction provides additional performance, an increase in strength of approximately 15%, reduced sheave and drum wear, and significantly enhanced drum spooling. As a result, operating depths can be extended up to approximately 6000 ft. (1830 m).
Bridon Tiger® 6R Bristar®

Bridon Tiger® 6R Bristar®

Bridon Tiger® 6R Bristar® is the most common used rope on friction winders with reliable performance, advanced diameter stability and lifetime with a Bristar® core.
