WRI® DyPac 18

Header EF

WRI®

DyPac 18

WRI® DyPac 18 series ia a compound rotation resistant rope construction consisting of an inner rope laid in one direction and an outer layer of strands laid in the opposite direction.

Applications

Applications

  • Construction cranes
  • Port & maritime cranes
  • Industrial Cranes
Advantages

Advantages

  • Increased lifting capacity & crush resistance
  • Smoother outer strand for efficiency on high speed hoisting lines
  • Advanced cushion core for superior service life
Features

Features

Compaction Dyform
Core IWRC
Steel Grades 1770, 1960 or 2160
Lay type Langs lay or Regular lay
Lay Direction RH or LH
Finish Bright or Galvanised

WRI® DyPac 18 specification

Note for more detailed information please download the brochure above.

Diameter Approx Mass WSC Min Breaking Force
Rope Grade
EEIP / 2160
in mm lb/ft kg/m tons kN
3/8 - 0.281 0.42 8.31 73.9
- 10 0.336 0.50 9.49 84.4
- 11 0.407 0.61 11.7 104
7/16 - 0.415 0.62 11.2 100
- 12 0.484 0.72 13.7 122
1/2 - 0.542 0.81 14.6 130
- 13 0.568 0.85 16.1 143
- 14 0.659 0.98 18.5 165
9/16 - 0.686 1.02 19.3 172
5/8 16 0.847 1.26 22.7 202
- 18 1.09 1.62 30.8 274
3/4 19 1.22 1.82 32.4 288
- 20 1.34 1.99 37.9 337
- 22 1.63 2.43 46.8 416
7/8 - 1.66 2.47 46.8 416
- 24 1.94 2.89 54.6 486
1 - 2.17 3.23 57.5 512
- 26 2.27 3.38 64.1 570
- 28 2.63 3.91 74.3 661
1 1/8 - 2.74 4.08 71.5 636
1  1/4 32 3.39 5.04 87.9 782

This table is for guidance purpose only with no guarantee or warranty (express or implied) as to its accuracy. The products described may be subject to change without notice, and should not be relied on without further advice from Bekaert.
