Bridon Dyform® 4

Header EF

Bridon®

Dyform 4

Bridon Dyform® 4 series ropes are compacted, single-layered ropes around a synthetic core. Higher minimum breaking force when compared to conventional 4-strand ropes.

Applications

Applications

  • Port & maritime cranes
Advantages

Advantages

  • Rotation resistant
  • Wear resistant
  • Ideal for unloading type deck cranes
  • Substantially less diameter reduction, resulting in longer life*
  • 80% more lifting cycles before reaching broken wire removal criteria*
Features

Features

Compaction Dyform
Core -
Steel Grades 1770, 1960 or 2060
Lay type Regular lay
Lay Direction RH or LH
Finish Galvanised

Bridon Dyform® 4 specification

Note for more detailed information please download the brochure above.

Tables

Diameter Nominal Length Mass MBF
1960
mm kg/m kN
10 0.429 87.4
11 0.510 106
12 0.613 126
12.7 0.680 141
13 0.724 148
14 0.822 171
15 0.944 196
16 1.07 224
17 1.21 253
18 1.35 283
19 1.50 315
20 1.67 350
21 1.86 385
22 2.01 423
22.2 2.11 438
23 2.23 462
24 2.41 504
25 2.63 546
25.4 2.70 564
26 2.83 591
28 3.31 685
28.6 3.45 715
30 3.83 787
32 4.37 895
33.5 4.77 981
34 4.87 1010
35.5 5.34 1102
36 5.44 1130
38 6.07 1260

This table is for guidance purpose only with no guarantee or warranty (express or implied) as to its accuracy. The products described may be subject to change without notice, and should not be relied on without further advice from Bekaert.
